General Information
Dielectric: Polypropylen (PP)
Metallisation: 99% Silver + 1% Gold
tan δ: 0,0002@1 kHz · 0,0001@10 kHz
Max. ambient temperature: 85°C/185°F
Highly recommended for new designs. Further voltages, capacities and custom labeling available on request.

MCap SUPREME EVO SilberGold

Since 2015, the MCap® SUPREME EVO SilverGold has been our undisputedtop capacitor model. It combines all our technical highlights, such as SilverGold metallisation, SUPREME and EVOLUTION winding technology and over 30 years of experience in the manufacturing of audiophile masterpieces into a unique capacitor type of equally unique musicality: finely nuanced and lively shining acoustic colours, which combine into a breathtaking, beautiful, live-like music experience with the utmost precision, presence and three-dimensional plasticity.

Metallised polypropylene as the dielectric guarantees low tolerances and the highest standards of safety in use thanks to its self-healing properties. After running through our new top-quality winding process, the capacitor winding is potted by hand into aluminium tubes to minimise microphony. The directly gold-plated, asymmetrical pure copper wires make it possible to assemble it in a classic, horizontal style or vertical; the shorter lead also indicates the capacitor's outer foil.

Thanks to its Oil impregnition, the MCap® SUPREME EVO SilverGold.Oil offers even superior presence and dynamics.

MCap SUPREME EVO SilverGold.Oil
Order Code Capacity
[µF]
[VDC] Body
Ø*L [mm]
Wire
Ø*E/A [mm]
Retail
[€]
SESGO-1,0 1,0 ±2% 1000 36 * 28 1,0 * 35/60 69,90
SESGO-1,5 1,5 ±2% 1000 41 * 28 1,0 * 35/60 79,90
SESGO-2,2 2,2 ±2% 800 36 * 34 1,0 * 35/65 89,90
SESGO-2,7 2,7 ±2% 800 41 * 34 1,0 * 35/70 99,90
SESGO-3,3 3,3 ±2% 800 46 * 34 1,4 * 35/70 109,90
SESGO-3,9 3,9 ±2% 800 46 * 34 1,4 * 35/70 119,90
SESGO-4,3 4,3 ±2% 800 51 * 34 1,4 * 35/75 124,90
SESGO-4,7 4,7 ±2% 800 51 * 34 1,4 * 35/75 129,90
SESGO-5,1 5,1 ±2% 800 56 * 34 1,4 * 40/75 134,90
SESGO-5,6 5,6 ±2% 800 56 * 34 1,4 * 40/75 141,90
SESGO-6,2 6,2 ±2% 800 51 * 41 1,4 * 35/80 149,90
SESGO-6,8 6,8 ±2% 800 51 * 41 1,4 * 35/80 159,90
SESGO-7,5 7,5 ±2% 800 56 * 41 1,4 * 40/85 169,90
SESGO-8,2 8,2 ±2% 800 56 * 41 1,4 * 40/85 179,90
SESGO-10 10 ±2% 800 66 * 41 1,4 * 45/90 209,90
SESGO-15 15 ±2% 800 76 * 41 1,4 * 50/95 299,90
SESGO-22 22 ±2% 700 66 * 55 1,4 * 45/100 399,90
SESGO-33 33 ±2% 600 66 * 67 1,4 * 45/115 599,90
SESGO-47 47 ±2% 600 76 * 67 1,4 * 50/120 699,90
