General Information
Dielectric: Polypropylen (PP)
Metallisation: 99% Silver + 1% Gold
tan δ: 0,0002@1 kHz · 0,0001@10 kHz
Max. ambient temperature: 85°C/185°F
Highly recommended for new designs. Further voltages, capacities and custom labeling are available on request.

MCap SUPREME EVO SilverGold

Since 2015, the MCap® SUPREME EVO SilverGold has been our undisputedtop capacitor model. It combines all our technical highlights, such as SilverGold metallisation, SUPREME and EVOLUTION winding technology and over 30 years of experience in the manufacturing of audiophile masterpieces into a unique capacitor type of equally unique musicality: finely nuanced and lively shining acoustic colours, which combine into a breathtaking, beautiful, live-like music experience with the utmost precision, presence and three-dimensional plasticity.

Metallised polypropylene as the dielectric guarantees low tolerances and the highest standards of safety in use thanks to its self-healing properties. After running through our new top-quality winding process, the capacitor winding is potted by hand into aluminium tubes to minimise microphony. The directly gold-plated, asymmetrical pure copper wires make it possible to assemble it in a classic, horizontal style or vertical; the shorter lead also indicates the capacitor's outer foil.

MCap SUPREME EVO SilverGold
Order Code Capacity
[µF]
[VDC] Body
Ø*L [mm]
Wire
Ø*E/A [mm]
Retail
[€]
SESG-0,0010 0,0010 ±5% 1000 11 * 23 0,6 * 35/40 29,90
SESG-0,010 0,010 ±3% 1000 11 * 13 0,6 * 35/40 31,90
SESG-0,10 0,10 ±2% 1000 17 * 23 0,6 * 35/45 33,90
SESG-0,15 0,15 ±2% 1000 21 * 23 0,8 * 35/45 35,90
SESG-0,22 0,22 ±2% 1000 26 * 23 0,8 * 35/50 37,90
SESG-0,33 0,33 ±2% 1000 31 * 23 0,8 * 35/50 41,90
SESG-0,47 0,47 ±2% 1000 31 * 23 0,8 * 35/50 45,90
SESG-0,68 0,68 ±2% 1000 36 * 23 0,8 * 35/55 51,90
